| Brand Name: | HUAXING |
| Model Number: | RI0984 |
| MOQ: | 1 |
| Payment Terms: | T/T |
RI0984 type special high voltage glass enamel resistor
1. Purpose: used for high voltage electronic equipment and other high voltage electronic circuits.
2. Packaging form: coated with gray insulating paint
3. Appearance size and main technical indicators:
Note ①: The resistance and allowable deviation are directly marked on the main body of the product.
|
70℃ rated dissipation (W) |
nominal resistance (MΩ) |
element the limit voltage① (kv) |
outline dimension mm |
maximum weight (g) |
|||
| Lmax | Dmax | l | d | ||||
| 1 | 50 | 4 | 18.5 | φ8.5 | 30±2 | φ1±0.05 | 3.4 |
| Note: ① When the nominal resistance exceeds the critical resistance of 16MΩ, the maximum voltage of the component is applied | |||||||
Main performance parameters:
| model | Rated power (W) at 70℃ | Resistance range (Ω) | Resistance tolerance deviation |
temperature coefficient (×10-6/℃) |
Component limit voltage (v) |
| RI0984 | 1 | 50M | ±3% | ± 200 | 4000 |
|
|
