| Brand Name: | HUAXING |
| Model Number: | RI0983 |
| MOQ: | 1 |
| Payment Terms: | T/T |
RI0983 type special high voltage glass enamel resistor
1. Purpose:
used for high-voltage electronic equipment and other high-voltage electronic circuits.
2. Packaging form:
coated with gray insulating paint
3. Appearance size and main technical indicators:
Note ①: The resistance and allowable deviation are directly marked on the main body of the product.
|
70℃ rated dissipation (W) |
nominal resistance (MΩ) |
element the limit voltage① (k V) |
outline dimension mm |
maximum weight (g) |
|||
| Lmax | Dmax | l | d | ||||
| 2 | 100 | 8 | 30 | φ8.5 | 30±2 | φ1±0.05 | 4.2 |
| Note: ① When the nominal resistance exceeds the critical resistance of 32MΩ, the maximum voltage of the component is applied | |||||||
Main performance parameters:
| model | Rated power (W) at 70℃ | Resistance range (Ω) |
Resistance tolerance deviation
|
temperature coefficient (×10-6/℃) |
Component limit voltage (v) |
| RI0983 | 2 | 100M/300M | ±3% | ± 200 | 8000 |
|
|
